Production of shrink PVC filmand different product of it: sleeve, half-sleeve, canvas, band, label...

Thin PVC shrink film from 20 microns

Thin PVC shrink film

Thin shrink PVC film can be used for individual or group packaging of various food products, cans, bottles, haberdashery and household products. The main difference from the «classic» shrink films is the thickness of 20 microns, which means a smaller volume and weight.

Scope of use:

  • Food
  • Bakery, candy, biscuits («screen» and «tv box» type of packaging)
  • Egg trays
  • Fish sneers, chips in «screens» (for supermarkets)
  • Baby food, yoghurts (packing food sets on the tray and the single products)
  • Children's goods
  • Disposable tableware
  • Household chemicals
  • Cosmetics and perfumes (boxes and bottles)
  • Twine, ropes
  • Small appliances and utensils (frying pans, ceramics, etc.)
  • Consumer goods (clothespins, threads, lids, etc.)
  • Textiles (bedding on substrate)
  • Ironing boards
  • Wallpapers
  • Glass mesh
  • Finishing materials
  • Paint ribbons, scotch tape
  • Toilet seats
  • Books
  • Magazines and discs
  • Toys and board games
  • Check tapes
  • Printing products (booklets, leaflets, flyers)
  • Group battery pack
  • Medical equipment (surgical instruments, test tubes, thermometers, etc.)

Technical parameters

Density: 1,27 g/sm3 (±0,07)

Thickness: 20 µm (±3)

Half sleeve width: 250 to 600 mm

Half-sleeve length: 550 to 630 m

Softening temperature: +60°C

Sitting operating temperature: +80°C to + 120°C

Storage temperature: -20°C to +20°C

Color in mass: transparent

Cardboard sleeve weight: 2.55 kg/PM

Elongation at break in longitudinal direction: 155,24%

Elongation at break in transverse direction: 161,98%

Tensile strength in longitudinal direction: 63.6 MPa

Tensile strength in transverse direction: 61.7 MPa

Static coefficient of friction: 0.2792

The proportion of shrinkage: 30-20%/35-35% (to be agreed with the customer)

Comparison of PVC Shrink Films
